Specifications

• ENGINE

  add remove
  • Cylinders:
    2
  • Engine Stroke:
    4-Stroke
  • Horsepower (bhp):
    106
  • Torque (Ft Lbs):
    77
  • Torque RPM:
    6250
  • Bore (mm):
    97
  • Stroke (mm):
    68
  • Displacement (cc):
    998
  • Compression Ratio:
    10.8:1
• TRANSMISSION

  add remove
  • Transmission Type:
    Manual
  • Number Of Speeds:
    5
  • Primary Drive (Rear Wheel):
    Belt
  • Reverse:
    Yes
  • Final Drive Ratio:
    2.82
• TECHNICAL SPECIFICATIONS

  add remove
  • Length (in):
    105
  • Width (in):
    59.3
  • Height (in):
    45.1
  • Wheelbase (in):
    68
  • Ground Clearance (in):
    4.5
  • Dry Weight (lbs):
    699
  • Payload Capacity (lbs):
    440
  • GVWR (lbs):
    1188
  • Fuel Capacity (gal):
    6.6
  • Storage Capacity (cuft):
    1.6
  • Storage Capacity (l):
    44
  • Engine Displacement to Weight (cc):
    1.43
• SUSPENSION

  add remove
  • Front Suspension Type:
    Independent Double A-Arm
  • Front Travel (in):
    5.7
  • Rear Suspension Type:
    Twin Sided Swing Arm
  • Rear Travel (in):
    5.7
  • Number Rear Shock Absorbers:
    1
• WHEELS & TIRES

  add remove
  • Front Tire Width:
    165
  • Front Tire Aspect Ratio:
    65
  • Front Wheel Diameter:
    14
  • Rear Tire Width:
    225
  • Rear Tire Aspect Ratio:
    50
  • Rear Wheel Diameter:
    15
  • Front Tire (Full Spec):
    KR21 165/65 R14
  • Rear Tire (Full Spec):
    KR21 225/50 R15
• BRAKES

  add remove
  • Front Brake Type:
    Dual Hydraulic Disc
  • Front Brake Diameter (in):
    10.2
  • Rear Brake Type:
    Hydraulic Disc
  • Rear Brake Diameter (in):
    10.2
